Szczegóły Produktu:
|
| Wysuwanie pionowe: | 45 siła N | Wysuwanie boczne: | 35 siła N |
|---|---|---|---|
| Boczna siła wyciągania Zaolejona: | 33powierzchnia(N) | Wewnętrzna objętość: | 1,6 cm3 |
| Min. promień krzywizny przedmiotu obrabianego: | 35 mm | ||
| Podkreślić: | Przyssawka płaska do blachy,elektrozawór pneumatyczny przyssawka,Odciąganie blachy metalowej serii SFF |
||
| SFF 50 N-G3F | ||||
| ① ② ③ ④ | ||||
| ①Seria | ②Średnica | ③Materiał i twardość | ④Gwint połączeniowy | |
| SFF | 30-φ30mm | N-NBR | 60 | G2F-G1/4 gwint żeński |
| 40-φ40mm | NG-NBR | 45 | G3F-G3/8 gwint żeński | |
| 50-φ50mm | HK - Guma o bardzo wysokiej temperaturze | 65 | G2M-1/4 gwint męski | |
| 60-φ60mm | HD - Wysoka temperatura/bez śladów materiał |
60 | M10M-M10×1.5 gwint męski | |
| 80-φ80mm | M14M-M14×1.5 gwint męski | |||
| 100-100mm | RA-Adapter prostokątny | |||
| 125-125mm | ||||
| Wybór | ||||||
| Model | Gwint połączeniowy G2M |
M1OM | M14M | G2F | G3F | RA |
| SFF30N-□ | SFF30N-G2M | 8FF30N-M1OM | SFF30N-M14M | SFF30N-G2F | SFF30N-G3F | SFF30N-RA |
| SFF40N-□ | SFF40N-G2M | 8FF40N-M1OM | SFF40N-M14M | SFF40N-G2F | SFF40N-G3F | SFF40N-RA |
| SFF50N-□ | SF50N-G2M | SFF50N-M10M | SFF50N-M14M | SFF50N-G2F | SFF50N-23F | SFF5ON-RA |
| SFF60N-□ | SFF60N-G2M | 8F60N-M1OM | SFF60N-M14M | SFF6ON-G2F | SFF60N-G3F | SFF60N-RA |
| SFFBON-□ | 8FF80N-G2M | 8FF80N-M10M | SFF8ON-M14M | SFFBON-G2F | SFF8ON-G3F | SFF8ON-RA |
| SFF100N-□ | 8FF100N-G2M | SFF100N-M1OM | SFF100N-M14M | SFF100N-G2F | SFF100N-G3F | 8F100N-RA |
| SFF125N-□ | 8FF125N-G2M | 8FF125N-M1OM | SFF125N-M14M | SFF125N-C2F | SFF125N-3F | 8FF125N-RA |
| Model | Gwint połączeniowy G2M |
M1OM | M14M | G2F | G3F | RA |
| SFF30NG-□ | SFF30NG-G2M | SFF30NE-M1OM | SFF30N-M14M | SFF30N-G2F | SFF30NG-G3F | SFF30NG-RA |
| SFF40NG-□ | SFF40NE-G2M | 8FF40NE-M1OM | SFF40N-M14M | SFF40N-G2F | SFF40NG-G3F | SFF40NG-RA |
| SFF50NG-□ | SFF50NE-G2M | SFF50NE-M1OM | SFF50N-M14M | SFF50N-G2F | SFF50NG-G3F | 8FF50NE-RA |
| SFF60NG-□ | SFF60NE-G2M | SFF6ONE-M10M | SFF60N-M14M | SFF60N-G2F | SFF60NG-G3F | 8FF60NE-RA |
| SFF80NG-□ | SFF8ONE-G2M | SFFBONE-M1OM | SFF80N-M14M | SFF80N-G2F | SFF8ONG-G3F | SFF80NG-RA |
| SFF100NG-□ | SFF100NE-C2M | 8FF100NE-M1OM | SFF100N-M14M | SFF100NG-G-2F | SFF100NG-G3F | SFF100NG-RA |
| SFF125NG-□ | SFF125N-G2M | 8FF125NE-M1OM | SFF125N-M14M | SFF125NE-G2F | 8FF125NE-G3F | 8FF125NE-RA |
| Model | Gwint połączeniowy G2M | G2F | G3F | Model | Gwint połączeniowy G2M | G2F | G3F |
| SFF30HK-□ | SFF30HK-G2M | SFF30HK-G2F | SFF30HK-G3F | SFF30HD-□ | SFF30HD-G2M | SFF30HD-G2F | SFF30HD-63F |
| SFF40HK-□ | SFF40HK-G2M | SFF40HK-G2F | SFF40HK-G3F | SFF40HD-□ | SFF40HD-G2M | SFF40ED-G2F | SFF40HD-63F |
| SFF50HK-□ | SFF50HK-G2M | SFF50HK-G2F | SFF50HK-G3F | 8FF50HD-□ | SFF50HD-G2M | SFF50ED-G2F | SFF50HD-63F |
| SFF60HK-□ | SFF60HK-G2M | SFF60HK-G2F | SFF60HK-G3F | 8FF60HD-□ | SFF60HD-G2M | SFF60HD-G2F | SFF60HD-G3F |
| SFF80HK-□ | SFF80HK-G2M | SFFB0HK-G2F | SFF80HK-G3F | SFF80HD-□ | SFF80HD-G2M | SFF80ED-G2F | SFFB0HD-63F |
| SFF100HK-□ | SFF100HK-G2M | SFF100HK-G2F | SFF100HK-G3F | SFF100HD-□ | SFF100ED-G2M | SFF100HD-G2F | SFF100HD-G3F |
| SFF125HK-□ | SFF125HK-G2M | SFF125HK-G2F | SFF125HK-G3F | 8FF125HD-□ | SFF125HD-G2M | SFF125HD-G2F | SFF125HD-G3F |
| Parametry techniczne | ||||||||
| Model | Pionowa siła wyciągania N |
Boczna siła wyciągania N |
Boczna siła wyciągania oleista powierzchnia(N) |
Wewnętrzna objętość cm³ |
Min. promień krzywizny obrabianego przedmiotu mm |
Waga g |
Zalecana średnica węża mm |
MPQ szt. |
| SFF30 | 45 | 35 | 33 | 1.6 | 35 | 11 | 6 | 1 |
| SFF40 | 72 | 54 | 51 | 3.5 | 47.5 | 13 | 6 | 1 |
| SFF50 | 112 | 90 | 86 | 7.5 | 70 | 20 | 8 | 1 |
| SFF60 | 145 | 102 | 93 | 12.6 | 81 | 26 | 8 | 1 |
| SFF80 | 288 | 212 | 190 | 35 | 115 | 43 | 8 | 1 |
| SFF100 | 445 | 322 | 308 | 60 | 141 | 57 | 8 | 1 |
| SFF125 | 660 | 475 | 400 | 115 | 165 | 145 | 10 | 1 |
